Dimensions |
86mm * 103mm * 20mm |
Material |
PC+ armored glass |
Weight |
130g |
Voltage |
DC 12V (5V – 30V) |
Current |
<160mA 12V |
Interface |
Wiegand, RS232, RS485 |
Image Sensor |
640 x 480 CMOS, 30fps |
View Angle |
Horizontal 63’, Vertical 51’ |
Scan Angle |
Roll: 360’, Pitch: ± 60’, Skew: ± 50’ |
Support Code |
On by default: EAN13, EAN8, UPC-A, UPC-EO, UPC-E1, Code 128, Code 39, Code 93, CodaBar, QR Code, PDF417, DataMatrix Off by default, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code 11, MSI Plessey, RSS-14, RSS-Limited, RSS-Expanded’ |
Reading Distance |
30 – 230mm (6-inch mobile phone, wechat QR payment code) |
Resolution |
1D: ≥ 5mil / 2D: ≥ 10mil |
Symbol Contrast |
≥ 25% |
Recognition Mode |
Active / passive, with support for induction mode |
Scan Code Feedback Beep |
Beeping: the light indicates scanning code |
Support Card |
ISO14443A / B, support ID card physical ID, NFC mobile phone card |
Operating Temperature |
-20°C ~ 60°C |
Operating Humidity |
5%RH~95%RH (Non-Condensing) |
Storage Temperature |
-40°C ~ 80°C |
Ambient Lighting |
0-80000Lux |
Static |
Contact discharge ± 6KV and air discharge ± 12KV |
IP Protection |
Front IP54 |
